Main technical performance Rated current:
|
Contact diameter (mm)
|
0.8
|
1
|
1.5
|
2
|
|
Rated current (A)
|
3
|
5
|
10
|
15
|
Contact resistance:
|
Contact diameter (mm)
|
0.8
|
1
|
1.5
|
2
|
|
before test (mΩ)
|
6
|
6
|
3
|
3
|
|
after test (mΩ)
|
10
|
10
|
5
|
5
|
Insulation resistance: Under standard conditions: ≥2000MΩ
Under high temperature conditions: ≥1000MΩ
Under humid conditions: ≥10MΩ
Voltage resistance: Under standard conditions: 500V
Under low pressure conditions:250V
Mechanical life: 500 cycles
Performance specification Temperature rating: -55 ℃ ~ +125 ℃
Relative humidity: at 40 ℃ ± 2 ℃, 90% ~ 95%
Vibration: at 10 Hz~2000 Hz, acceleration 196 m/s²
Shock: 980 m/s²
Atmospheric pressure: 101.3 KPa ~ 1.33 KPa
Acceleration: 780 m/s².
